Product Description

3003/3103/3A21 Aluminum and Aluminium Tube Pipe

In the annealing state, 3003 3A21 Aluminum Tube Pipe their plasticity is very high. In the semi cold hardening, the plasticity is good, the cold is hardened, the plasticity is low, the corrosion resistance is good, the weldability is good, and the cutting property is bad. A low load part, such as an oil tank, a gasoline or a lubricating oil pipe, that requires high plasticity and good weldability, and is used in liquid or gas medium.

Specification:
Alloy:3003,3103,3A21
Temper:O, F, H112, H18
Normal size:23.5X1.91x0.32, 14.5X1.73x0.32, 16X2x0.32, 16X1.7x0.32, 14.55X2x0.32, 25X1.5x0.32, 18X2x0.32
Application:Water tank

Chemical Composition of 3003 3A21 Aluminum Tube Pipe
Alloy	Si	Fe	Cu	Mn	Mg	Cr	Ni	Zn	Ca	V	Ti	Other	Min.A1
3003	0.6	0.7	0.05-0.2	1.0-1.5	-	-	-	0.1	-	-	-	0.15	Remainder
3A21	0.6	0.7	0.20	1.0-1.6	0.05	-	-	0.15	-	-	0.10-0.20	0.15	Remainder

Physical Property of 3003 3A21 Aluminum Tube Pipe
Alloy	Temper	Wall thickness /mm	Room temperature Test Result
			Tension Strength/MPa	Yield Strength/MPa	Elongation/%
			Tension Strength/MPa	Yield Strength/MPa	A_50mm	A
			Not less than
3003	O	All	95 ~ 130	35	25	22
	H112	≤1.60	95	35	-	-
	H112	>1.60	95	35	25	22
	F	All	-	-	-	-
3A21	H112	All	≤165	-	-	-
